Holden VS-VY L67 S/Charged V6 3.8L
If you're building for real power, especially in a L67 Holden platform, the Whipple 2.4L twin-screw is worlds ahead in performance and upgradability. The factory L67 M90 is okay, but it's not in the same league as a properly tuned Whipple.
Below is a comparison of the Holden V6 L67 Eaton Roots blower unit to a Whipple Twin Screw 2.4L Gen 4 blower:
1. SUPERCHARGER DESIGN & ROTOR TECHNOLOGY
Feature | L67-Eaton M90 | Whipple Gen 4 (2.4L) |
---|---|---|
Type | Roots-style | Twin-screw |
Rotor Design | 3-lobe Roots | Latest Gen 4 intermeshing screw rotors |
Compression | External (in intake) | Internal (in housing) |
Efficiency | less efficient | Optimized axial & radial flow for maximum volume |
The Gen 4 Whipple uses a refined and efficient rotor profile that reduces turbulence and friction, resulting in cooler air and significantly more power per PSI.
2. EFFICIENCY & BOOST CHARACTERISTICS
Attribute | L67- M90 | Whipple Gen 4 |
---|---|---|
Thermal Efficiency | Moderate to low | Very high |
Intake Temp Under Boost | Hot | Much cooler |
Boost Capability | ~10–12 PSI max (efficiently) | 20–25 PSI capable with minimal heat soak |
RPM Range | Strong low-end, fades at high RPM | Strong low-end and continues pulling hard through redline |
3. HORSEPOWER POTENTIAL
System | Max Power Potential |
---|---|
Eaton M90 | ~350–400 HP (typical street builds) |
Whipple Gen 4 2.4L | 600+ HP |
The Gen 4 Whipple is engineered for serious high-horsepower builds and motorsport applications, while the M90 remains a moderate OEM-grade option.
4. BUILD QUALITY & ENGINEERING
Feature | L67 M90 | Whipple Gen 4 |
---|---|---|
OEM-Style Casing | Yes | No – billet or cast aluminium cases |
Rotor Coating | Standard | Advanced Teflon-coated for wear and thermal resistance |
Bypass Valve | Basic internal | High-efficiency integrated bypass system |
Drive System | 6-rib (typical OEM) | 6/8/10-rib billet independent drive system (as supplied by Yella Terra) |
5. SOUND & RESPONSE
-
Eaton M90: Noticeable whine under load with a traditional OEM-style sound. Boost comes on early but drops off at higher RPM.
-
Whipple Gen 4: Deeper, more aggressive tone with a crisp whine. Smooth, linear boost curve that continues to build power from idle to redline.
The Whipple Gen 4 L67 Upgrade absolutely crushes the Eaton M90 in efficiency, power delivery, cooling, durability, and overall engineering. If you're chasing real, reliable power in a Holden V6 platform, the Gen 4 Whipple with the AiR to AiR manifold is the only serious choice.
